3616-SXXX-XXXS1R01 Current Rating:0.5AMP Current Resistance:30mΩ Max Insulation Resistance:100mΩ Min Withstand Voltage:500V AC/Minute Operation Temperature:﹣40℃ to +105℃ Contact Material:Phosphor Bronze Cap Material:LCP(UL94V-0),Nature Contact Plating:Au Or Sn over Ni Flatness:＜80Pins The"M"Is 0.12mm MAX ≥80Pins The"M"Is 0.15mm MAX[查看]

http://www.jerrytouch.cn/Products/08mmmtbtbtxboardtobo.html

3616-S080-XXXG1R Current Rating:0.5AMP Current Resistance:30mΩ Max Insulation Resistance:100mΩ Min Withstand Voltage:500V AC/Minute Operation Temperature:﹣40℃ to +105℃ Contact Material:Phosphor Bronze Cap Material:LCP(UL94V-0),Nature Contact Plating:Au Or Sn over Ni Flatness:＜80Pins The"M"Is 0.12mm MAX ≥80Pins The"M"Is 0.15mm MAX[查看]

http://www.jerrytouch.cn/Products/08mm80pmtbtbtxboardt.html

3616-PXXX-XXXS1R01 Current Rating:0.5AMP Current Resistance:30mΩ Max Insulation Resistance:100mΩ Min Withstand Voltage:500V AC/Minute Operation Temperature:﹣40℃ to +105℃ Contact Material:Phosphor Bronze Cap Material:LCP(UL94V-0),Nature Contact Plating:Au Or Sn over Ni Flatness:＜80Pins The"M"Is 0.12mm MAX ≥80Pins The"M"Is 0.15mm MAX[查看]

http://www.jerrytouch.cn/Products/08mmgzbtbtxboardtobo.html

3615-SXXX-XXXS1R01 3615-SXXX-XXXS1R0X 3615-SXXX-XXXS1RX Current Rating:0.5AMP Current Resistance:65mΩ Max Insulation Resistance:1000mΩ Min Withstand Voltage:250V AC/Minute Operation Temperature:﹣40℃ to +105℃ Contact Material:Phosphor Bronze Contact Plating:Au Or Sn over Ni Insulator Material:Polyester(UL94V-0) Standard:LCP+30％GF[查看]

http://www.jerrytouch.cn/Products/08mmmzjzboardtoboard.html

3615-PXXX-XXXS1R01 Current Rating:0.5AMP Current Resistance:65mΩ Max Insulation Resistance:1000mΩ Min Withstand Voltage:250V AC/Minute Operation Temperature:﹣40℃ to +105℃ Contact Material:Phosphor Bronze Contact Plating:Au Or Sn over Ni Insulator Material:Polyester(UL94V-0) Standard:LCP+30％GF[查看]

http://www.jerrytouch.cn/Products/08mmgzjzboardtoboard.html
